用处与概述/Brief Introduction：

全半手动的注塞泵式膏体酱灌装设备生产线机这是我集团公司适应能力市場供给研发的产品的。机用户通过SUS304不锈钢管注塞泵式压力容器检验泵继续执行灌装设备生产线，且集半手动的上盖、半手动的旋盖、汽车电器电器为集成，成本入门，征地赔偿范围小，常见用于药业有限公司、食材、化肥、所有、画妆品等餐饮行业的溶液纸盒包装，包含GMP规范性追求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

特征 /characteristic：

◆通过注塞泵式的计量泵执行命令包装，可用于多种多样黏稠度液體，精准度较高；泵的结构类型通过快接式拆解单位，方便洗涤、清洁消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆柱塞泵式收费泵活塞式环不锈钢原料要根据领域及固态部分的与众不同选取硅聚氨酯，四氟丁二烯或另一不锈钢原料，个性化场景选取瓷器不锈钢原料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC控住体系，定频调速器，自动式化层度高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装设备，半自动数值功能键。Lack of bottle filling, automatic counting function◆装量更改简易，可以次更改全不量值溯源泵的充填量，也可根据各种量值溯源泵开始微幅更改；工作简易，更改飞速。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装针头设立防漏滴提升装置，充填时溜进瓶底包装，慢慢持续增长，防范有气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆整个设备可不适用与众不同产品规格的罐子，调正用简，可在短期间内顺利完成。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆主机按GMP请求的设计。The machine designed according to the requirements of GMP

技术工艺性能/technic parameter：

支持塑料瓶子規格Size of bottles	20-1000ml（只能根据耍求订作）20-1000 - ml (according to your need）
适合可乐瓶直径约Apply the bottle diameter	¢20-¢150mm
适用于盖子规模Apply the lid specifications	¢20-¢70mm
生产销售工作能力 production capacity	四头包装：1000-2500瓶/分钟 Four filling head: 1000-2500 bottles per hour 八头装罐：2500-4000瓶/一小时 Eight head filling: 2500-4000 bottles per hour 12头装罐：4000-6000瓶/半小时 12 head filling: 4000-6000 bottles per hour
装量随机误差The load error	±1%
旋盖适合率Screw cover percent of pass	≥99%
电power supply	380V，50HZ
工率power	3.0KW
氧气减压阀gas sources	0.4-0.75MPA
车速抑制speed control	变頻变频调速variable speed
